WSP-DT380 Thermal POS Printer
High speed & Performance with stylish, compact design.
This compact POS printer features; high speed, auto-cutter, support for text & graphics, easy maintenance and self diagnostics. Unusual for this class of printer, the DT380 is also available with a Bluetooth interface.
It is the ideal solution for POS receipting, kitchen printer, electronic weighing, measuring equipment, gaming and lottery systems, etc.
WSP-DT380
Features & Benefits
- 80mm Thermal POS printer
- High speed printing up to 170mm/sec - for rapid receipting
- Supports both full and partial autocutter- to simplify receipt issuing
- RS232, USB, Parallel interfaces with optional Bluetooth or Wireless LAN available - compatible with most POS terminals
- Powered from 24V DC (supplied with AC adapter) - POS industry standard
WSP-DT380 Specifications
| SPECIFICATION | WSP-DT380 |
| Colours | Black & Red |
|---|---|
| Printing | Direct Thermal - CLAMSHELL auto load |
| Characters per line | 64 (max) |
| Resolution | 203 dpi, 8 dots/mm |
| Print width | 3 inch (72mm, 576 dots) |
| Printing speed | 170mm/sec |
| Auto Cutter | Full & Partial Cut |
| Magnetic Stripe Reader | Option: ISO 7810 / 7811 / 7812 1, 2 & 3 Track Reading |
| Dimensions (WxDxH) | 126 x 165.5 x 108.2mm |
| Net Weight | 801g (excluding paper roll) |
| Interface | USB or RS232 (standard) Options; Parallel, Bluetooth, WiFi |
| Cash Drawer Output | 24V DC |
| Paper Capacity | Thermal paper roll 80mm wide, 80mm diameter (80m approx length) |
| Power Required | 24VDC (2.7A) Supplied with 100/240 VAC, 50/60Hz power adapter |
| Print head life | 100km |
| Autocutter life | 700,000 cuts |
| Relative humidity | 30 to 85% (non condensing) |
| Operating temperature | -10~50°C |
| Drivers | Windows (CE, 7, Vista, XP), Linux, Android OS |
