Woosim WSP i series Rugged Thermal Printers
The WSP-i family of rugged industrial printers are certified IP54 resistant to water and dust. They have been tested to operate from -30 to plus 70 degrees C and can also withstand a drop of 1.8m onto concrete making them ideal for mobile receipting, door to door selling (or collecting) and outdoor event POS.
They have RS232 and Bluetooth interface as standard with USB or Wireless LAN options available. Other options on selected models include magnetic stripe reader (MSR) and Smart card reader. With high capacity Li-ion batteries as standard, these printers can be used for a prolonged period before recharging (which only takes 4 hours).
The WSP-i350 and WSP-i450 models are certified by Apple Inc.; "Made for iPod", "Made for iPhone", and "Made for iPod" which means that an electronic accessory has been designed to connect specifically to iPod, iPhone, or iPad, respectively, and has been certified by the developer to meet Apple performance standards (Note *1).
WSP-i350
Features & Benefits
- 58, 80 or 112mm rugged thermal mobile printer
- Durable Rugged Design - for tough working environments
- Water & dust resistant construction - for outdoor, field or heavy industrial use
- Wide operating temperature range - for extreme outdoor weather
- Compact size & light-weight - easily carried
- High Speed Thermal (up to 80mm/sec) - ideal for on-demand receipt or ticket printing
- RS232C, USB & Bluetooth or wireless LAN interface options - compatible with most terminals
- Fast charging, clip-in, Li-ion battery - never be stuck with a flat battery
- Easy paper loading by CLAMSHELL design - for fast, easy paper loading
- Graphic LCD with backlight - for clear operator feedback/printer status information
- Ideal for use with smartphones or PDA - drivers and SDK's available
- Rechargeable battery, charger and data cable included - ready to use
- Shoulder strap or belt clip options available - for outdoor/field use
WSP i Series Specifications
| SPECIFICATION | WSP-i250 | WSP-i350 | WSP-i450 |
| Printing System | Direct Thermal, Clamshell Easy load | ||
|---|---|---|---|
| Case Colour(s) | Dark Grey | Orange | Dark Grey |
| Cutting System | Tear bar | ||
| Media | Thermal paper roll, Thermal label roll | ||
| Paper width | 57/58mm | 80mm | 112mm |
| Roll Diameter | 50mm | ||
| Roll Length | 24m (Note *2) | ||
| Characters per line | 42 | 64 | 92 |
| Character size | 9x24, 12x24, 16x24, 24x24 dots | ||
| Resolution | 203 dpi, 8 dots/mm | ||
| Print width | 2 inch (48mm) 384 dots |
3 inch (72mm) 576 dots |
4 inch (104mm) 832 dots |
| Printing speed | 80mm/second | 60mm/second | 70mm/second |
| Magnetic Stripe Reader | Tracks 1, 2 & 3 | Tracks 1 & 2 or Tracks 2 & 3 | Tracks 1, 2 & 3 |
| Smart Card Reader | ISO 7816 Compliant (EMV level 1 Certified) 1 SAM (Security Application Module) |
n/a | ISO 7816 Compliant (EMV level 1 Certified) 2 SAM (Security Application Module) |
| LCD | 128 x 32 dots FSTN (Blue LED Backlight) | ||
| Dimensions (WxDxH) | 92 x 141 x 60mm (MSR) 92 x 145 x 60mm |
120 x 131 x 58mm | 151 x 136 x 63mm |
| Weight (incl paper) | 406.5g | 435g | 596g |
| Interfaces | RS-232C & Bluetooth, USB & WiFi (options) | ||
| Data Buffer | 1M bytes | ||
| Flow Control | Software - XON/XOFF (Hardware flow control not supported) | ||
| Barcodes supported | 1D: Code128, Code39, I2/5, Code93 UPC, EAN, KAN, JAN, CODABAR | ||
| 2D: PDF417, QR Code, DATA Matrix, Micro PDF417, Truncated PDF417 | |||
| Sensors | Head open, Paper out, Black mark | ||
| Battery | 7.4V DC Li-ion 1.8 or 2.2A h | 7.4V DC Li-ion 2.2A h | |
| Standby Current | 38mA (printer in 'sleep' mode) | ||
| Full Recharge | 4 hours, provides 1 hour continuous printing @ 25% duty cycle | ||
| Charger | Input: 100~240V AC 50~60Hz, Output:8.4V DC | ||
| MCBF: head | 50 km | ||
| MCBF: mechanism | 37,000,000 lines | ||
| Operating temp. | -30 to 70°C | ||
| Humidity | 30 to 80% | ||
